QDR
4500 Technical Manual
9-4
SQKEYPAD
The SQKEYPAD utility allows you to control motor
functions and turn on the laser. If there is a problem
with the Operator Control Panel, use this utility to
isolate a panel or a motion problem.
Note:
SQKEYPAD will not work for some motor
drives until the motor drive calibrations are
completed.
Running SQKEYPAD
At the MENU> prompt, type:
SQKEYPAD<Enter>
The screen that appears (seen at right) allows you to
control various motion functions and toggle the laser on
and off by using the numerical keypad on the right side
of the computer keyboard.
Use this utility to determine whether the motor/x-ray
system or the operator control panel is at fault.
8
TABLE
IN
.
ARM
RIGHT
0
ARM LEFT
2
TABLE
OUT
1
ARM
AP
6
TABLE
RIGHT
5
LASER
LIGHT
On/Off
4
TABLE
LEFT
9
TABLE
UP
3
TABLE
DOWN
The SQKEYPAD Screen
7
ARM
LATERAL
