QDR



4500 Technical Manual

8-2

Signal Distribution

LEDs

Signal Voltage Source Jumpers Refer

to...

D1 On +7VDC Int. Voltage Reg. JP1 (panel) Out

Off TZ drive - - JP2 (dist) Out

D5 On +5VDC Int. Voltage Reg. JP3 (C-arm) Out

D7 On +28VDC Ext Console

Power

Circuit Breakers

Figure

5-1

D9 On +15VDC Ext Console

Power

CB Drive Normally

D10 On -15VDC Ext Console

Power

1TZ In

- - +24VDC Ext Console

Power

2TY In

D11

Off TY

DRIVE

3TX In

D12

Off TX

DRIVE

4AR In

D13

Off AR

DRIVE

5AY In

D14

Off AY

DRIVE

Notes:

Voltage indicators = green; motor drive status = red

If red led is on, there is a failure in the PCB. The CB should be tripped.

Communications Controller

Jumpers Refer to...

JP1 (IRQ) at 10 In

JP2 (IRQ) Out Figure 5-17

JP3 (IREQA) Out

JP4 (IREQB) In

JP5 (E-OUT) at C In
