Hologic QDR 4500 - Cables; Miscellaneous

To Next Page

To Previous Page

Section 5 - Remove & Replace

5-47

Figure 5-23. Drum Outer Bearings

Part Number Description

Used

250-0046 Drum Outer Bearing

Figure 5-24. Drum Inner Bearings

Part Number Description

Used

250-0045 Drum Inner Bearing

Cables

Part Number Description

Used

180-0185 Cable, A/D Analog Data

180-0189 Cable, A/D Digital Data

180-0190 Cable, Power Multiplex

180-0191 Cable, DAS Communication

180-0194 Cable, Arm Faceplate

180-0195 Cable, Safety Switch

180-0213 Cable, Fan, X-Ray Controller

180-0328 Cable, X-Ray Signal (EMI, replaces 180-0193)

180-0332 Cable, C-Arm Signal (EMI, replaces 180-0186)

180-0334 Cable, AR Drive (EMI)

180-0335 Cable, C-Arm Power (EMI)

180-0336 Cable, TX Drive (EMI)

180-0337 Cable, TY Drive (EMI)

Miscellaneous

Part Number Description

Used

010-0926 Cable Kit

010-1026 A/SL Enhancement Kit A,SL

UPS-100-0033 UPS, 60Hz

UPS-100-0034 UPS, 50Hz
