QDR

4500 Technical Manual
5-46
Figure 5-18. Computer Assemblies
Part Number Description
Used
On
120-0017 Floppy Drive, 1.44MB 3.5"
120-0081 Optical Disk Drive, Internal Half Height
120-0083 SCSI Interface Board
120-0116 Hard Drive, 1GB minimum
120-0120 JAZ Drive, 1GB
120-0145 CD-ROM,12X MINIMUM
120-0148 VIDEO ACCELERATOR, 4 MB PCI
120-0154 Network Card
120-0160 HARD DRIVE 2 GB JAZ REMOVABLE
130-0009 Floppy Drive, 1.2MB 5.25"
140-0042 Communications Controller PCB
180-0136 Optical Disk Cable, Internal
JAZ-ISA-DOSV9-
110
Kit Jaz Drive Isa Dosv9 Option
JAZ-PCI-WIN-110 Kit Jaz Drive Pci Win Option
Figure 5-19. Aperture Assembly FRUs (QDR 4500A and SL)
Part Number Description
Used
On
140-0068 Aperture Motor PCB
180-0267 Cable, Aperture Motor Signal
255-0032 Aperture Position Belt
320-0041 Aperture Stepper Motor
Figure 5-22. Front Drum Assembly FRUs
Part Number Description
Used
On
010-0627 Filter Drum Stepper Motor Assembly
255-0030 Drum Wheel Belt 150 Teeth
255-0031 Drum Wheel Belt 130 Teeth
