QDR

4500 Technical Manual
5-44
Figure 5-13. Laser Assembly
Part Number Description
Used
On
010-0682 Laser Assembly
Figure 5-14. Rear C-Arm FRUs
Part Number Description
Used
On
140-0087 Analog to Digtl Convrtr Board
(ADC, EMI, replaces 140-0054)
Figure 5-15. Power Module FRUs
Part Number Description
Used
On
101-0032 15V Power Supply (VDE version)
101-0033 28V Power Supply (VDE version)
140-0056 Power Controller Board
160-0001 Line Filter, 20A
310-0018 Circuit Breaker, 20 Amp 2 Pol
370-0047 Isolation Transformer (VDE version)
485-0011 Power On Lamp, Neon Green
Figure 5-16. Power Control Panel FRUs
Part Number Description
Used
On
140-0056 Power Controller Board
310-0029 Ckt Breaker, 2 Pole, 220v 6amp
310-0030 Ckt Breaker, 2 Pole, 240v 3amp
310-0032 Circuit Breaker, 120vac, 1amp
310-0033 Circuit Breaker, 120vac, 3amp
310-0035 Circuit Breaker, 120vac, 10amp
310-0039 Circuit Breaker, 120 Vac 4 Amp
465-0031 Switch, SPDT Power, Rocker
485-0043 X-Ray On LED, Green, 24V
