QDR
4500 Technical Manual
6-4
TX, TY, AR, AY
Check... Refer to...
Belt
Motor Controller Board
heading,
Encoder coupling hose Section 2
Encoder coupling clamp Figure 5-1, 5-2, 5-3, 5-4, 5-6, 5-7
Motor controller board Section 8
Motor/gear case for the motor
subsystem in question
TY (on A and W models only)
Left and right end panels on table for proper installation.
This may cause problems if reversed. (Left 030-1376, right
030-1838).
TZ
To... Refer to...
Operate pedestal motors by service switches
located on the TZ Drive board
TZ Drive Board
heading, Section 2
Block diagram and interconnection chart for
the TZ motor subsystem
Troubleshoot TZ drive problems
Note:
The
pedestal drive test cable (180-0320) is used to
isolate pedestal problems from driver problems.
Section 8
Do not run the TZ motors for more than 30 seconds continuously. These pedestal motors are
rated at a 10% duty cycle. Exceeding the rating causes an overheat condition and shuts down the
motor. After shut down, the motors must cool for at least 5 minutes before running.
CAUTION:
Running any motor subsystem to its limit (in either direction) does not damage the
motor. However, if the motor encoder is not properly calibrated it may be damaged.
TX, TY, TZ, AR, AY
To... Run... Refer to...
Perform simple table and C-arm
movements
Motor Control Pad
(computer motion
control)
The Hologic Main Menu, select:
1. Utility
2. Emergency motion
Perform precise table and C-arm
movements
SQDRIVER
Motor Calibration
heading, and
Motor$XX
(for the specific motor),
Section 4
Monitor all motion parameters
Troubleshoot problems encountered
initiating motion from the Operator's
Control Panel
Control Panel Controller Board
heading, Section 2
Hardware checker SQCHECK, 080-0476
To Next Page
