ACUIX™ PTZ High Speed Analog Dome Installation and Configuration Guide
Document 800-05662 Rev C 105
06/10
Configuring Sectors
Note Remember you access the OSD by pressing 90  Preset.
Task/Action (with Default) Notes
Programming a Sector
1. Select 2 Display Options  2 Sectors  ON to turn on the
Sector title display.
2. Select 6 Function Programming  5 Program Sector.
3. Select a Sector ID number to program. Press Iris Open (+).
4. Using the joystick to scroll through the list of numbers and
letters, enter a 24-alphanumeric name for the sector. Press Iris
Open (+).
The instructions Go to lower left corner and press
Iris Open when done display.
5. Press Focus Far (-) to switch to PTZ mode to gain control over
the joystick and position the picture to the lower left corner of
the sector.
6. Press Focus Near (+) to switch to menu mode to access the
controller keyboard. Press Iris Open (+).
The instructions Go to upper right corner and press
Iris Open when done display.
7. Press Focus Far (-) to switch to PTZ mode to gain control over
the joystick and position the picture to the upper right corner of
the sector.
8. Press Focus Near (+) to switch to menu mode to access the
controller keyboard.
9. Press Iris Open (+)
 Focus Far (-)  Iris Close (-) to save
the sector, program another sector or exit.
This menu is available only when using
MAXPRO-mode, VCL, UTP and Pelco P
and D protocols
Changing a Sector Name Location on the Monitor
• Select 2 Display Options  7 Change Sector Name Loc 
Use either arrows or the joystick to move the text up or down
the monitor to position as required.
If the dome has overlapping sectors
displaying at the same time, the two titles
alternate at 1.5 second intervals.
Turning Sector ID Titles ON or OFF
• Select 2 Display Options 2 Sectors  ON or OFF (default).
