ACUIX™ PTZ High Speed Analog Dome Installation and Configuration Guide
Document 800-05662 Rev C 121
06/10
Lower Dome Model Numbers and Specifications
New indoor and outdoor pendant housings are being phased into the ACUIX Series
product line. All new model numbers have the suffix V2 added to the end of the original
part number as indicated in Table A-8.
Note When new V2 housing (see Table A-3) and lower domes (see Table A-8) are
ordered in pairs, the combined part numbers use the housing part and start
with the prefix HDX instead of HDH.
Caution The new V2 housings (see Table A-3) and lower dome models (see
Table A-8) MUST be installed with each other. For example, the lower
dome HDB00P0SWV2 must be installed with an HDH00PA00V2 housing.
The old and new models are not compatible with each other.
Table A-8 Lower Dome Model Numbers
Housing Lower Dome Model Lower Dome and Trim Ring
V2 V1
Pendant
(indoor or
outdoor)
HDB00P0SWV2 HDB00P0SW Smoked Lower Dome, White Trim Ring
HDB00P0SBV2 HDB00P0SB Smoked Lower Dome, Black Trim Ring
HDB00P0CWV2 HDB00P0CW Clear Lower Dome, White Trim Ring
HDB00P0CBV2 HDB00P0CB Clear Lower Dome, Black Trim Ring
In-ceiling
N/A HDB00D0CW Clear Lower Dome, White Trim Ring
N/A HDB00D0SW Smoked Lower Dome, White Trim Ring
N/A HDB00D0CB Clear Lower Dome, Black Trim Ring
N/A HDB00D0SB Smoked Lower Dome, Black Trim Ring
N/A HDB00D0GW Gold Lower Dome, White Trim Ring
N/A HDB00D0GB Gold Lower Dome, Black Trim Ring
Rugged
N/A HDB00R0CW Clear Lower Dome, White Trim Ring
N/A HDB00R0SW Smoked Lower Dome, White Trim Ring
