ACUIX™ PTZ High Speed Analog Dome Installation and Configuration Guide
Document 800-05662 Rev C 119
06/10
Scan Assembly Model Numbers and Camera Specifications
Table A-5 Scan Assembly Model Numbers with Camera Type
Camera Type Scan Assembly Model Camera Description Camera Model
NTSC
HDCAN0000 18X Color, 470 TVL HDXA
HDCJN0000 18X WDR/TDN, 530 TVL HDXJ
HDCFN0000 26X WDR/TDN, 530 TVL HDXF
HDCGN0000 35X WDR/TDN w/ EIS, 540 TVL HDXG
PAL
HDCAP0000 18X Color, 460 TVL HDXA
HDCJP0000 18X WDR/TDN, 520 TVL HDXJ
HDCFP0000 26X WDR/TDN, 520 TVL HDXF
HDCGP0000 35X WDR/TDN w/ EIS, 530 TVL HDXG
Table A-6 Pan and Tilt Specifications
Pan Speed Variable Pan speed can be programmable between 1–480°/sec.
Tilt Speed Variable Tilt speed can be programmable between 1–240°/sec.
Preset Speed < 0.5 seconds to any Preset
Preset Accuracy ± 0.1°
Table A-7 Camera Specifications
Camera Model HDXA HDXJ HDXF HDXG
Image sensor 1/4" type EX-view
HAD CCD
1/4” type EX-view
HAD CCD
1/4” type EX-view
HAD CCD
1/4” type Progressive
scan CCD
Lens 18X optical zoom, f =
4.1 mm (wide) to 73.8
mm (tele), F1.4 to
F3.0
18X optical zoom, f =
4.1 mm (wide) to 73.8
mm (tele), F1.4 to
F3.0
26X optical zoom, f =
3.5 (wide) to 91 mm
(tele), F1.6 to F3.8
35X optical zoom, f =
3.4 (wide) to 119 mm
(tele), F1.4 to F4.2
Horizontal
resolution
> 470 TVL (NTSC) > 530 TVL (NTSC)
> 520 TVL (PAL)
>530 TVL (NTSC) > 540 TVL (NTSC)
Movable IR Filter
(True Day Night -
TDN/NightShot)
No Yes Yes Yes
Wide Dynamic
Range (WDR)
No Yes, 128X Yes, 128X Yes, 128X
