36
Installation
Step 1: Set the Switches on
the Housing Interface Board
Figure 3-1
Penda
nt, In-ceiling, and Rugged Ho
using Interface Boards
Figure 3-2
Housing In
terface Board Layout
Field wiring access holes
Rugged Housin
g
Pendant Ho
using
In-ceiling Housing
Interface board
RS485 termination switch
SW1 shown in ON
position (terminated)
UTP/coaxial selection
SW2 shown ON (with
UTP enabled)
BNC connector
J4
J7
SW1
SW2
U3
Fan
Wiring access hole
J1
J6
If using contact inputs,
also removable
terminal blocks on J4
Removable
terminal blocks on
J1 and J6
J3
