42
Installation
Setting the Dome Address (SW1 to SW4)
Caution Each dome requires a unique address between 0000 and 9999. The
addressing scheme may be restricted due to the limitations of the
controller. For example, the HEGS5000/HEGS5001 controllers control
dome addresses 1 to 256 whereas the HJZTP controller controls dome
addresses 1 to 128.
1. Turn the arrows on rotary switches SW1, SW2, SW3 and SW4 to the number
required using Table 3-7 and Figure 3-6 for reference. For example:
• To set the dome address to CAM 0001, set SW1 = 1, SW2 = 0, SW3 = 0,
SW4 = 0.
• To set the dome address to CAM 0125, set SW1 = 5, SW2 = 2, SW3 = 1,
SW4 = 0.
Table 3-6 DIP Switch SW6 Baud Rate and Parity Settings
Baud Rate
and Parity
Values
Baud Rate Switch Position Parity Switch
Position
Other*
12345678
600 OFF OFF OFF OFF
1200
ON OFF OFF OFF
2400 OFF ON OFF OFF
4800 ON ON OFF OFF
9600 OFF OFF ON OFF
19200 ON OFF ON OFF
38400 OFF ON ON OFF
57600 ON ON ON OFF
115200 OFF OFF OFF ON
None OFF OFF OFF OFF
Even ON OFF OFF OFF
Odd OFF ON OFF OFF
* The defaults for SW6-7 and SW6-8 are OFF.
