ACUIX™ PTZ High Speed Analog Dome Installation and Configuration Guide
Document 800-05662 Rev C 117
06/10
Housing Model Numbers and Specifications
New indoor and outdoor pendant housings are being phased into the ACUIX Series
product line. All new model numbers have the suffix V2 added to the end of the original
part number as indicated in Table A-3.
Note When new V2 housing and lower domes (see Table A-8) are ordered in pairs,
the combined part numbers use the housing part and start with the prefix
HDX instead of HDH.
Caution The new V2 housings and lower dome models (see Table A-8) MUST be
installed with each other. For example, the lower dome HDB00P0SWV2
must be installed with an HDH00PA00V2 housing. The old and new
models are not compatible with each other.
Table A-3 Housing Model Numbers
Housing Model Description
V2 V1
HDH00DA00V2 HDH00DA00 In-ceiling
HDH00PA00V2 HDH00PA00 Indoor Pendant, White
HDH00BA00V2 HDH00BA00 Indoor Pendant, Black
HDH00WA00V2 HDH00WA00 Outdoor Pendant, White
N/A HDH00RA00 Rugged, White
Table A-4 Housing Specifications
Specification Indoor Pendant
Housing
Outdoor Pendant
Housing
In-ceiling
Housing
Rugged
Housing Height 7.5 in. (190.5 mm) 7.5 in. (190.5 mm) 6.7 in. (170.21
mm)
6.95 in (176.5 mm)
Housing Diameter 9.25 in. (235 mm) 10.0 in. (254 mm) 8.13 in. (206.45
mm)
10.52 in. (267.2 mm)
Housing Flange
Diameter
9.25 in. (235 mm) 9.25 in. (235 mm) 8.0 in. (203.2 mm) 8.0 in. (203.2 mm)
Housing Material Aluminum Aluminum Aluminum Aluminum
Lower Dome
Diameter
7.5 in. (191 mm) 7.5 in. (191 mm) 6.60 in. (168 mm) 7.5 in (191 mm)
