20
Introduction to the ACUIX PTZ Dome
Configuration Options
About the On-Screen Display (OSD) Menus
All ACUIX Series domes provide access to on-screen display (OSD) menus to set various
display, control, diagnostic and camera parameters based on user requirements. The
OSD is also where mimic tours, privacy zones, sectors, presets and preset tours are
programmed. To access the OSD with the ACUIX analog PTZ dome requires a monitor
and controller.
Table 1-1 ACUIX Series Terminology
Term Definition
dome The complete installed product including the housing, mount, bracket or
adapter, lower dome, and the scan assembly.
scan assembly The combination of firmware, electrical and mechanical components
including the camera and lens. The scan assembly is installed into the
housing and enclosed by a lower dome. The scan assembly is a
component of a dome.
camera The particular model camera purchased. The camera is a component of
the scan assembly.
housing The in-ceiling, indoor or outdoor pendant and surface mount, or rugged
upper enclosure. The housing contains the interface board that
determines the type of ACUIX installed (analog, digital or fixed). Housing
is a hardware component of the dome.
mount The hardware used to mount the housing to the applicable surface (for
example, a ceiling or wall). The mount is a hardware component used with
a specific type of housing. It may be included with the housing (for
example, the rugged or in-ceiling domes), or purchased separately (for
example, the indoor or outdoor pendant domes).
lower dome The clear or colored enclosure that covers the scan assembly and
attaches to the housing. It also includes the trim ring. The lower dome is
a hardware component of the dome.
