Before You Begin Configuring
Note The text displayed on the OSD with MAXPRO-mode is a shortened version of
the descriptions in Table 4-3.
Various presets are available for programming with all protocols with exceptions as noted.
Table 4-3 Special Presets Based on Protocol
Preset Function Protocol
72 Recover encrypted user login PIN and GUID All
73 Enable broadcast command receive mode MAXPRO-mode, VCL, VCL UTC, Diamond,
Pelco D or P
Pelco P_AD or Pelco D_AD (depending on
the hardware installation)
74 Disable broadcast command receive mode
75 Administrator / password/PIN settings
• 1. User Login PIN
• 2. Change PIN
• 5. System Info
• 6. Change Address, Protocol
All
76 Run Mimic Tour 1–16
MAXPRO-mode, VCL, VCL UTC, Pelco D or P77 Program Mimic Tour
78 Run Preset Tour 1–16
80, 81, 82 Run mimic tours 1, 2 and 3 MAXPRO-mode, VCL, VCL UTC, Pelco D or P
Pelco P_AD or Pelco D_AD (depending on
the hardware installation)
83, 84, 85 Program mimic tours 1, 2 and 3
86 Stop or end mimic tour programming sequence MAXPRO-mode, VCL, VCL UTC, Pelco D or P
87, 88, 89 Start/run preset tours 1, 2 and 3 MAXPRO-mode, VCL, VCL UTC, Pelco D or P
Pelco P_AD or Pelco D_AD (depending on
the hardware installation)
90 Setup menu (on-screen display/OSD)
MAXPRO-mode, VCL, VCL UTC, Diamond,
Pelco D or P
91, 97 and 99 Reserved
92 Toggles auto exposure or iris ON and OFF
(factory default is ON)
93 Toggles backlight compensation ON and OFF
(preset 92 /auto exposure must be ON)
