Honeywell ACUIX Installation And Configuration Guide

ACUIX™ PTZ High Speed Analog Dome Installation and Configuration Guide
Document 800-05662 Rev C 87
06/10
Task/Action with Default (HDXG Camera Models Only) Notes
Setting the Auto AE Mode
1. Select 5 Camera Options  2 Exposure Control  1 Auto
AE Mode.
2. Select from the available settings (see Table 5-2) displayed
below the menu options. The default mode is AER + 1.
The controller and the camera must be in
auto iris mode.
Setting the Manual AE Mode
1. Select 5 Camera Options  2 Exposure Control  2 Manual
AE Mode.
2. Select:
• Iris (default): to control the iris manually where the camera
controls the gain and shutter automatically.
• Gain: to manually control the gain where the camera
controls the iris and shutter automatically.
• Shutter: to control the shutter manually where the camera
controls the iris and gain automatically.
The controller must be set to manual iris
mode.
HDXG cameras only.
Table 5-2 Auto Exposure Control Mode Settings
Setting NightShot
Control
Auto
NightShot
Sensitivity
Digital Slow
Shutter
Auto AE Mode MAN NA OFF
Auto AER1 Mode AUTO HIGH OFF
Auto AER1 Mode AUTO MID OFF
Auto AE+ Mode MAN NA AUTO
Auto AE+ 1 Mode
(default)
AUTO HIGH AUTO
Auto AER + 2 Mode AUTO MID AUTO
Auto AER +3 Mode AUTO LOW AUTO
