78
Configuration
Configuring the Pan, Tilt and Zoom (PTZ) Dome Settings
Note Remember you access the OSD by pressing 90 Preset.
Task/Action (with Default) Notes
Turning the Pan and Tilt Speed Range (PASS) ON and OFF
Select 3 Control Options 1 PASS ON (default) or OFF. PASS is a function of the lens zoom
angle. The maximum pan and tilt speeds
are reduced when the lens zooms in. For
example, the pan and tilt functions are
slow when the camera is set at 12X zoom.
The higher the zoom magnification, the
slower the speed.
Turning the Auto Pivot ON or OFF
Select 3 Control Options 2 Auto Pivot ON or OFF (default). Track people passing directly underneath
the dome. The dome automatically turns
180 when it reaches its lower limit. It
continues to tilt up as long as the control
tilt function remains in the down position.
When the dome reaches its tilt up limit, it
returns to normal operation.
Changing the Manual Pan and Tilt Speed
Select 3 Control Options 4 Set Pan and Tilt Options 1 Manual
Speed
120°/sec, 240°/sec, or 480°/sec (default).
The maximum tilt speed is half of the
maximum pan speed.
To Next Page
