ACUIX™ PTZ High Speed Analog Dome Installation and Configuration Guide
Document 800-05662 Rev C 71
06/10
To exit or escape from a menu (VCL):
The monitor displays press Iris Close. Press Iris (-).
In VCL protocol, press Iris (+) to open a menu and Iris (-) to close a
menu. The OSD uses the terms Iris Open and Iris Close to mean the
same thing respectively. In some menus, you can also use these
keys to toggle between values.
To exit or escape from a menu (MAXPRO-mode or Diamond):
The monitor displays press Esc. When using an HJZTP controller, press lock.
Note In the event pressing lock does not exit the OSD and LCD menus, press F6
repeatedly until you are completely out of the menus. Each time you press F6 you
back up the menu structure one level (that is, to the previous screen).
Caution If you press F6 four times after you are out of the menus, the dome will
reset.
