Web Client Operation
179
Figure 12-50 3G Configuration Interface
Table 12-14 3G Configurations
Configuration Description
WLAN Type
Select a 3G network type to distinguish this 3G module from different
ISPs. Choose from WCDMA, CDMA1x, for example.
APN & Dial No.
APN and the Dial No. are important PPPoE parameters. The APN
(Access Point Name) and the Dial No. are automatically received by the
NVR after connecting to a 3G module.
Dial/SMS
Activate
Enable/disable Dial/SMS Activate. When enabled, if the user sends an
"ON" message by phone to the NVR, then the NVR dials and connects
with CDMA/GPRS. If the user sends an "OFF" message by phone to the
NVR, then the NVR breaks the link with CDMA/GPRS.
AUTH Authorization. Choose from PAP, CHAP, or NO_AUTH.
Username /
Password
Enter a username and password for logging onto the 3G network.
Pulse Interval
Configure a time for ending the 3G connection after you close the extra
stream monitor. For example, if you select 60 here, the NVR ends the
3G connection 60 seconds after you close the extra stream monitor.
Note: If the Pulse Interval is 0, then the system does not end the 3G
connection after you close the extra stream monitor.
Note: The Pulse Interval here is for the extra stream only. This field is
inactive if you are using a main stream monitor.
IP Address
Non-configurable. After the NVR connects to the network through
CDMA/GPRS, it receives an IP address, which displays here.
Wireless Signal
When the NVR connects to 3G through GPRS/CDMA, by clicking
SEARCH, you can see the signal strength.
Configuring the Mobile Settings
Go to SETUP NETWORK 3G Mobile.
