Ethernet Teaming 144
Table 13-4 Class: HP_EthernetTeam
Property name Property implementation
Description Local Area Connection # (for example Local Area
Connection #10)
ElementName Same as Caption
CIM_Collection
CIM_SystemSpecificCollection
Key:InstanceId System GUID for the team.
CIM_RedundancySet
• 0 (None)
LoadBalanceAlgorithm
• 1 (Other)
• 3 (Round Robin)
MaxNumberSupported Number of ports configured in team.
MinNumberNeeded 1
OtherLoadBalanceAlgorithm When LoadBalanceAlgorithm is 1 (Other),
OtherLoadBalanceAlgorithm is set to configured Load
Balance Algorithm (for example Automatic)
• 2 (Fully Redundant)
RedundancyStatus
• 3 (Degraded Redundancy)
• 4 (Redundancy Lost)
• 5 (Overall Failure).
• 2 (N+1)
TypeOfSet
• 3 (Load Balanced).
VendorIdentifyingInfo Identifying data for the RedundancySet.
HP_GroupRedundancySet
• 2 (OK)
GroupOperationalStatus
• 3 (Degraded)
• 6 (Error)
HP_EthernetTeam
ActiveMaximumTransmissionUnit Current maximum transmission unit in bytes
Speed The current bandwidth of the team in bits per second
TeamCapabilities[] Capabilities of an Ethernet Team (for example, Fast
Path Failover). See the Windows Ethernet Teaming
mof, HP_WinEthRedundancySet.mof
TeamCurrentOperatingMode Current operating mode of the Ethernet Team (for
example, 802.3ad Dynamic With Fault Tolerance)
TeamEnabledCapabilities[] Currently enabled capabilities of the Ethernet Team.
(for example, Fast Path Failover)
