HT2800T_en_c.doc Page 152 of 275
Fiber
lenght
Extraction/
Derivatization
20mm
<20 The instrument moves the
needle to have the needle tip just
under the septum, then expose
the fiber moving only the plunger.
Cover
Under septum,
33mm
47mm
0-20mm
Fiber
20<depth<28 The instrument moves the
needle 28mm over the final
position, then moves the plunger
to expose 20 mm of fiber and if
necessary, up to 8mm of fiber
holder.
Under septum,
33mm
47mm
0-8mm
Fiber holder
28<depth<47 The instrument moves the
needle 28mm over the final
position, then moves the plunger
to expose 20 mm of fiber and
8mm of fiber holder and, if
necessary, it moves the needle
down up to 19mm further.
Cover
33mm
47mm
0-19mm
Needle
8mm
