Creating a cluster manually
These steps need to be configured only on the administrator switch or on the switch which
will be the administrator in a created HGMP cluster.
In this mode, you need to manually add member switches to the cluster.
1. Run:
system-view
The system view is displayed.
2. Run:
cluster
The cluster view is displayed.
3. Run:
ip-pool administrator-ip-address { mask-length | mask }
The range of private IP addresses used in a cluster is set.
This command can be run only before the cluster is set up. If the cluster is set up, you
are not allowed to change the range of private IP addresses used in the cluster.
NOTE
The private IP addresses used by a cluster cannot be the same as any IP address on the device.
4. Run:
build cluster-name
Names of the administrator switch and the cluster are configured and the cluster is
created.
This command can only be run on the administrator switch and the switch that does
not join any cluster.
Creating a cluster automatically
These steps need to be configured only on the administrator switch or on the switch which
will be the administrator in a created HGMP cluster.
In this mode, the administrator switch prompts you whether to add all the existing candidate
switches to the cluster.
1. Run:
system-view
The system view is displayed.
2. Run:
cluster
The cluster view is displayed.
3. Run:
ip-pool administrator-ip-address { mask-length | mask }
The range of private IP addresses used in a cluster is set.
This command can be run only before the cluster is set up. If the cluster is set up, you
are not allowed to change the range of private IP addresses used in the cluster.
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 3 HGMP Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
91

Huawei Quidway S5700 Series Specifications

General

Category	Switch
Operating Temperature	0°C to 45°C
Relative Humidity	5% to 95% (non-condensing)
Series	Quidway S5700
Forwarding Performance	Up to 96 Mpps
Ports	24 or 48 x 10/100/1000Base-T ports
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C
Fixed GE Ports	24 or 48
Uplink Ports	4 x GE SFP ports
Routing Protocols	RIP, OSPF, BGP
Management	SNMP, RMON, CLI, Web
VLAN	4094 VLANs
PoE	Optional
