Huawei Quidway S5700 Series User Manual

Role:Administrator switch
management vlan id : 10
Cluster multicast MAC address : 0180-c200-000a(default)
Cluster auto-join : disabled
Handshake timer:10 sec
Handshake hold-time:60 sec
IP pool:10.0.0.1/8
Logging host:4.0.0.1
SNMP host:3.0.0.1
FTP server:2.0.0.1
SFTP server:2.0.0.2
cluster-member ftp-timeout: 300 sec(default)
Cluster SNMP NAT capability : enabled
Cluster FTP NAT capability : enabled
There are 4 member(s) in the cluster, and 0 of them are down.
Step 10 Verify the configuration.
l Member switches access the FTP server in NAT mode.
<HUAWEI_3.Member-3> cluster-ftp
Trying 10.0.0.1 ...
Press CTRL+K to abort
Connected to 10.0.0.1.
220 FTP service ready.
User(10.0.0.1:(none)):hgmp
331 Password required for hgmp.
Enter password:
230 User logged in.
[ftp]
l A device out of the cluster accesses the FTP server in the cluster in NAT mode.
# Configure an FTP server on Member-2. The configuration details see Configuration Files,
and are not mentioned here.
# Calculate the port number reserved for the FTP protocol of a member switch in the cluster.
The member ID of Member-2 is 2. Using the formula for computing port numbers reserved
for a cluster ( Interface number reserved for a cluster = Base interface number + Member
number*2) , you can obtain that the reserved port number, which is used by Member-2 to
enable the FTP server, is 53248 + 2*2 = 53252.
# Run the FTP client program on the PC and set up an FTP connection with Member-2 in
NAT mode.
NOTE
A device out of the cluster accesses the FTP server in the cluster in NAT mode. IP address of the FTP
server is that of the management VLANIF interface on the administrator switch. The FTP server uses
a port number reserved in the cluster instead of the commonly-used 21.
ftp> open 1.0.0.1 53252
Connected to 1.0.0.1.
220 FTP service ready.
User (1.0.0.1:(none)): hgmp
331 Password required for hgmp.
Password:
230 User logged in.
ftp>
----End
Configuration Files
l Configuration file of Administrator-1.
#
sysname Administrator-1
#
vlan batch 10
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 3 HGMP Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
126

Huawei Quidway S5700 Series Specifications

General

Category	Switch
Operating Temperature	0°C to 45°C
Relative Humidity	5% to 95% (non-condensing)
Series	Quidway S5700
Forwarding Performance	Up to 96 Mpps
Ports	24 or 48 x 10/100/1000Base-T ports
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C
Fixed GE Ports	24 or 48
Uplink Ports	4 x GE SFP ports
Routing Protocols	RIP, OSPF, BGP
Management	SNMP, RMON, CLI, Web
VLAN	4094 VLANs
PoE	Optional
