0002-0002-0002 1 S5700
0001-0001-0001 0 S5700
Step 5 Create a cluster.
NOTE
Following steps can be performed only on the administrator switch.
# On the administrator switch, set the range of IP addresses that can be assigned to the cluster
to 10.0.0.0/8, in which the IP address assigned to the administrator switch is 10.0.0.1/8.
[Administrator-1] cluster
[Administrator-1-cluster] ip-pool 10.0.0.1 8
# Create a cluster named HUAWEI on the administrator switch.
[Administrator-1-cluster] build HUAWEI
[HUAWEI_0.Administrator-1-cluster]
After the previous configuration, check information about the cluster to which the device
belongs. You can find that the device name is changed, the cluster name is HUAWEI, and the
management VLAN ID is 10.
[HUAWEI_0.Administrator-1-cluster] display cluster
Cluster name:"HUAWEI"
Role:Administrator switch
management vlan id : 10
Cluster multicast MAC address : 0180-c200-000a(default)
Cluster auto-join : disabled
Handshake timer:10 sec
Handshake hold-time:60 sec
IP pool:10.0.0.1/8
No logging host configured
No SNMP host configured
No FTP server configured
No SFTP server configured
cluster-member ftp-timeout: 300 sec(default)
Cluster SNMP NAT capability : enabled
Cluster FTP NAT capability : disabled
There are 1 member(s) in the cluster, and 0 of them are down.
On the administrator switch, check information about candidate switches, you can find all the
candidate switches and their types.
[HUAWEI_0.Administrator-1-cluster] display cluster candidates
MAC HOP IP PLATFORM
0004-0004-0004 2 S5700
0003-0003-0003 1 S5700
0002-0002-0002 1 S5700
Step 6 Add member switches.
NOTE
l Following steps can be performed only on the administrator switch.
l Take the mode of automatically adding member switches as an example. To add member switches
manually, see Adding a Member Switch.
# Add all candidate switches to the cluster.
[HUAWEI_0.Administrator-1-cluster] auto-build
Collecting candidate list, please wait...
Candidate list:
Name Hop MAC Address DeviceType
Member-1 1 0002-0002-0002 S5700
Member-2 1 0003-0003-0003 S5700
Member-3 2 0004-0004-0004 S5700
Warning: Add all to cluster?(Y/N) y
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 3 HGMP Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
134
