NOTE
Multiple member switches can be configured simultaneously through incremental configuration. For
configuration details, see Example for Configuring the Incremental Configuration Function for an
HGMP Cluster.
Step 10 Verify the configuration.
l Member switches access the FTP server in non-NAT mode.
< HUAWEI_3.Member-3> ftp 2.0.0.1
Trying 2.0.0.1 ...
Press CTRL+K to abort
Connected to 2.0.0.1.
220 FTP service ready.
User(2.0.0.1:(none)):hgmp
331 Password required for hgmp.
Enter password:
230 User logged in.
[ftp]
l Devices out of the cluster access the FTP server in the cluster in non-NAT mode.
# Configure an FTP server on the corresponding member switch (Member-2). The
configuration details see Configuration Files, and are not mentioned here.
# Run the FTP client program on the PC and set up an FTP connection with Member-2 in
non-NAT mode.
NOTE
Devices out of the cluster access the FTP server in the cluster in non-NAT mode. The IP address of
the FTP server is that of the management VLANIF interface on the member switch. The FTP server
uses a port number reserved in the cluster instead of the commonly-used 21.
ftp> open 10.0.0.2
Connected to 10.0.0.2
220 FTP service ready.
User (10.0.0.2:(none)): hgmp
331 Password required for hgmp.
Password:
230 User logged in.
ftp>
----End
Configuration Files
l Configuration file of Administrator-1.
#
sysname Administrator-1
#
vlan batch 10
#
cluster enable
ntdp enable
ntdp hop 5
ntdp timer 10
ndp enable
#
interface Vlanif10
ip address 1.0.0.1 255.0.0.0
#
interface GigabitEthernet0/0/1
port link-type trunk
port trunk allow-pass vlan 10
ntdp enable
ndp enable
#
interface GigabitEthernet0/0/2
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 3 HGMP Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
136
