Configuration Roadmap
The configuration roadmap is as follows:
1. Create a cluster and configure basic HGMP functions for the cluster according to the steps
described in Example for Configuring Basic HGMP Functions for a Cluster.
2. Disable SNMP NAT on the administrator switch (The function is enabled by default.)
NOTE
Related configurations of cluster NAT must be performed on the administrator switch.
3. Configure routes on the administrator switch and member switches respectively to ensure
that reachable routes exist between SNMP host and member switches.
4. Assign an IP address to the SNMP host.
Data Preparation
To complete the configuration, you need the following data:
l Management VLAN ID of the cluster, that is 10
l IP address of the SNMP host, that is 3.0.0.1/8
l IP address of VLANIF 10 that is 1.0.0.1/8 and a reachable route between VLANIF 10 and
the SNMP host
l Address pool of the cluster, that is 10.0.0.0/8
l IP address of the administrator switch used in the cluster, that is 10.0.0.1/8
Procedure
Step 1 Configure a management VLAN.
# Create VLAN 10 on the device and add interfaces of the administrator switch and member
switches to VLAN 10.
# Configure the administrator switch.
<Quidway> system-view
[Quidway] sysname Administrator-1
[Administrator-1] vlan 10
[Administrator-1-vlan10] quit
[Administrator-1] interface gigabitethernet 0/0/1
[Administrator-1-GigabitEthernet0/0/1] port link-type trunk
[Administrator-1-GigabitEthernet0/0/1] port trunk allow-pass vlan 10
[Administrator-1-GigabitEthernet0/0/1] quit
[Administrator-1] interface gigabitethernet 0/0/2
[Administrator-1-GigabitEthernet0/0/2] port link-type trunk
[Administrator-1-GigabitEthernet0/0/2] port trunk allow-pass vlan 10
[Administrator-1-GigabitEthernet0/0/2] quit
[Administrator-1] interface gigabitethernet 0/0/3
[Administrator-1-GigabitEthernet0/0/3] port link-type trunk
[Administrator-1-GigabitEthernet0/0/3] port trunk allow-pass vlan 10
[Administrator-1-GigabitEthernet0/0/3] quit
[Administrator-1] interface vlanif 10
[Administrator-1-Vlanif10] quit
# Configure member switch 1.
<Quidway> system-view
[Quidway] sysname Member-1
[Member-1] vlan 10
[Member-1-vlan10] quit
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 3 HGMP Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
149
