After the previous configuration, check information about the cluster to which the administrator
switch belongs. You can find that the public log host, SNMP host, FTP server, and SFTP server
are configured successfully.
[HUAWEI_0.Administrator-1-cluster] display cluster
Cluster name:"HUAWEI"
Role:Administrator switch
management vlan id : 10
Cluster multicast MAC address : 0180-c200-000a(default)
Cluster auto-join : disabled
Handshake timer:10 sec
Handshake hold-time:60 sec
IP pool:10.0.0.1/8
Logging host:4.0.0.1
SNMP host:3.0.0.1
FTP server:2.0.0.1
SFTP server:2.0.0.2
cluster-member ftp-timeout: 300 sec(default)
Cluster SNMP NAT capability : enabled
Cluster FTP NAT capability : enabled
There are 4 member(s) in the cluster, and 0 of them are down.
Step 10 Disable SNMP NAT on the administrator switch.
[HUAWEI_0.Administrator-1] cluster
[HUAWEI_0.Administrator-1-cluster] undo cluster-snmp-nat enable
Step 11 Configure the routes of member switches to ensure that reachable routes exist between member
switches and the SNMP host.
# Configure member switch 1.
[HUAWEI_1.Member-1] ip route-static 3.0.0.0 8 10.0.0.1
# Configure member switch 2.
[HUAWEI_2.Member-2] ip route-static 3.0.0.0 8 10.0.0.1
# Configure member switch 3.
[HUAWEI_3.Member-3] ip route-static 3.0.0.0 8 10.0.0.1
NOTE
Multiple member switches can be configured simultaneously through incremental configuration. For
configuration details, see Example for Configuring the Incremental Configuration Function for an
HGMP Cluster.
Step 12 Configure the SNMP agent function on member switches.
# Configure member switch 1.
[HUAWEI_1.Member-1] snmp-agent target-host trap address udp-domain 3.0.0.1 params
securityname cluster
# Configure member switch 2.
[HUAWEI_2.Member-2] snmp-agent target-host trap address udp-domain 3.0.0.1 params
securityname cluster
# Configure member switch 3.
[HUAWEI_3.Member-3] snmp-agent target-host trap address udp-domain 3.0.0.1 params
securityname cluster
Quidway S5700 Series Ethernet Switches
Configuration Guide - Network Management 3 HGMP Configuration
Issue 01 (2011-10-26) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
155

Huawei Quidway S5700 Series Specifications

General

Category	Switch
Operating Temperature	0°C to 45°C
Relative Humidity	5% to 95% (non-condensing)
Series	Quidway S5700
Forwarding Performance	Up to 96 Mpps
Ports	24 or 48 x 10/100/1000Base-T ports
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C
Fixed GE Ports	24 or 48
Uplink Ports	4 x GE SFP ports
Routing Protocols	RIP, OSPF, BGP
Management	SNMP, RMON, CLI, Web
VLAN	4094 VLANs
PoE	Optional
