Huawei SmartAX MA5608T User Manual

Device Step Remarks
2. Configure a service port. Create a service port on the ONU to
receive the video monitoring data. The
data is transmitted upstream to the OLT
through an uplink port.
Data Plan
Table 17-1 provides the OLT data plan, and Table 17-2 provides the ONU data plan.
Table 17-1 Data plan for configuring video monitoring data transmission over Ethernet-OLT
side
Item Data
VLAN
l Uplink port: 0/19/0
l Inband management VLAN: smart VLAN 8
l Service VLAN: smart VLAN 100
Inband management IP
address
192.168.50.20/24
GPON service board
l Port: 0/3/1
l ONU ID: 1
l ONU authentication mode: SN
l ONU SN: 48575443E6D8B541
DBA profile
l Profile name: VideoMonitoring
l Type: type3
l Assured bandwidth: 20 Mbit/s
l Maximum bandwidth: 50 Mbit/s
ONU line profile
l Profile ID: 10, bound to DBA profile VideoMonitoring
l GEM port ID: 0 (used for transmitting inband management
service stream)
l GEM port ID: 1 (used for transparently transmitting video
monitoring service stream)
l T-CONT ID: 5
ONU management mode SNMP
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
17 Electrical Service Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1798

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
