M.48 Part. N. 8000 H1344 (10-2009)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
• Connection of tilt sensor (SM only)
Connect the drop sensor as shown in the gure.
• Connection of back stop.
Connect the stop sensor as shown in the gure.
• Threading of steering sleeve cables
Secure the cables with the clip provided.
• Fastening of instrument holder plate connectors
Fasten the instrument and diagnostics connector using the fastening clips
provided. Fit the plug into the diagnostics connector.
