M.50 Part. N. 8000 H1344 (10-2009)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
• Fastening wiring
Fasten the wire harness to the frame with a clamp as shown in the picture.
• Fastening wiring
Fasten the back stop cable to the frame with a strap as shown in the gure.
• Fastening wiring
Fasten the back stop cable to the frame with a strap as shown in the gure.
• Fastening wiring
Fasten the wire harness to the frame with two clamps as shown in the picture.
