Husqvarna TE 310 - Page 83

E.13Part. N. 8000 H1344 (10-2009)
GENERAL OPERATIONS
8) TE-SMR: disconnect the cooling fan (1) from the main wiring harness.
Detach the thermoswitch (2) from the main wiring harness.
Remove the two screws (3) and the coolant expansion tank (4).
1
1
3
4
2
