6. Parameter
6.1 Parameter
6-35 ME0342-4B
[57] Ball Screw Lead Length (Parameter No. 77)
No. Name Unit Input range
Default initial value setting
77 Ball screw lead length mm 0.01 to 999.99 In accordance with actuator
Sets ball screw lead length.
A value suited to the actuator characteristics is set at shipment.
Caution
● Changing the setting will not only make operation at the instructed speed,
acceleration/deceleration or travel distance impossible but also cause an alarm or
malfunction to occur.
[58] Axis Motion Type (Parameter No. 78)
No. Name Unit Input range
Default initial value setting
78 Axis motion type -
0: Linear axis
1: Rotary axis
In accordance with actuator
Sets the type of actuator to use.
Connecting actuator Set value Remarks
Linear axis 0 Actuator other than rotary type
Rotary axis 1 Rotary type actuator
Caution
● Do not attempt to change the setting. This may lead to alarms or malfunctions.
