A–4
6400 Line Matrix Printers Setup Guide, Cabinet and Pedestal Models
Thickness Not to exceed 0.025–inch (0.064 cm), including
backing sheet.
*On pedestal models, when using the rear paper exit, the maximum form width is
16 inches (40.64 cm).
**On cabinet models, forms longer than 12 inches can be used by opening the front and
rear printer doors.
Printer Dimensions and Weight
Cabinet Models
Height: 41 inches (103.3 cm)
Width: 27 inches (68.6 cm)
Depth: 29 inches (73.7 cm)
32.5 inches (82.6 cm) with power stacker
Weight: 225 lbs. (102.1 kg) unpacked
246 lbs. (107.8 kg) unpacked with power stacker
285 lbs. (129.3 kg) packed
306 lbs. (135 kg) packed with power stacker
Pedestal Models
Height: 35.5 inches (90.2 cm)
Width: 24.6 inches (62.5 cm)
Depth: 30 inches (76.2 cm)
Weight: 120 pounds. (54.4 kg) unpacked
160 pounds. (72.6 kg) packaged
