2–25
Chapter 2. Setting Up the Printer
Attach the Input Paper Shelf and Output Basket
Paper Supports
Output Basket
Optional Input
Paper Shelf
Figure 2–14. Attaching the Input Paper Shelf and Output Basket
1. Slide the two paper supports toward the center of the support shaft.
Position them so that they divide the space between the tractors into
three approximately equal segments. See Figure 2–14.
2. Place the output basket in the holes on the back of the printer.
3. Place the input paper shelf (which is an optional feature) in the holes in
the front of the pedestal base.
