6400 Line Matrix Printers Setup Guide, Cabinet and Pedestal Models
Connect the Interface and Power Cables (Pedestal Models)
DANGER:
<1> Before powering on the printer ensure the printer is plugged into an
appropriate power source. Refer to Chapter 2 of the Setup Guide for
information on the proper source.
<4> Do not connect or disconnect any communication port, teleport,
attachment connector, or power cord during an electrical storm.
<5> Power off the print and disconnect the power cord before connecting or
disconnecting communication port, teleport, or attachment cable
connector.
1. Verify that the voltage source at the printer site conforms to the
requirements specified on page 2–6. Make sure that the printer power
switch is set to Off. (See Figure 2–23.)
2. Open the box containing the power cord, printer ribbon, and operator
panel overlay label. Refer to Appendix A, “Printer Specifications,” for
recommended cables.
3. Referring to Figure 2–23, connect the (customer-supplied) interface
cable from the host computer to the appropriate printer interface
connector:
a. Remove the cover from the I/O connector(s) you have selected.
b. Attach the cable connector to the printer interface connector.
4. Plug the power cord into the printer AC power connector, then into the
AC power outlet (see Figure 2–23).
