IBM 6400 Setup Guide

A–6
6400 Line Matrix Printers Setup Guide, Cabinet and Pedestal Models
Electrical Characteristics
Input Voltage
Line Voltage
Design Range
Line
Frequency
RMS Current
500 LPM 1000 LPM 1500 LPM
88–140 V RMS 47–63 Hz 6A @ 88 V 6A @ 88 V 8A @ 88 V
178–270 V RMS 47–63 Hz 3A @ 178 V 3A @ 178 V 5A @ 178 V
Power Consumption
6400–050
6400–P50
Operating DP Mode Standby
120 VAC
60 Hz
All H’s Max Typical
Not Energy
Star
Energy Star
Watts 210 180 80 21
BTU/Hour 720 620 275 75
VA 300 270 120 36
Operating DP Mode Standby
220 VAC
50 Hz
All H’s Max Typical
Not Energy
Star
Energy Star
Watts 210 170 80 22
BTU/Hour 720 580 275 75
VA 340 280 130 41
