IBM 6400

2–15
Chapter 2. Setting Up the Printer
Remove the Platen Protective Foam
Platen Protective Foam
Support Shaft
Forms
Thickness
Lever
Figure 2–6. Removing the Platen Protective Foam
1. Rotate the platen protective foam toward the front of the printer and out
from under the support shaft. Remove the platen protective foam.
