2–53
Chapter 2. Setting Up the Printer
Set the Top-of-Form
Forms
Thickness
Lever
Figure 2–48. Raising the Forms Thickness Lever
1. Raise the forms thickness lever as far as it will go. The
“CLOSE PLATEN” message will appear on the operator panel. Press any
key on the operator panel to silence the alarm. See Figure 2–48.
TOF Indicator
Vertical Position Knob
Paper Perforation
Left Tractor Door
Figure 2–49. TOF Indicator
2. Locate the TOF indicator. It is the small tab located on the left tractor
door. See Figure 2–49.
3. Turn the vertical position knob up or down to align the top of the first
print line with the TOF indicator. See Figure 2–49.
