3–8
6400 Line Matrix Printers Setup Guide, Cabinet and Pedestal Models
Printing the Current Configuration
Before you begin changing parameter values for the printer, you may wish to
print out a record of the current configuration, including any active values
that you have recently modified. If you have not changed any parameter
settings, the current configuration is the factory default configuration.
There are two methods for printing the current configuration: the first
method is to press the Printer Configuration key, as shown in the following
procedure.
Step
Key Result Notes
1. Make sure the printer is on.
2. Press:
Stop
NOT READY
The printer must be in
NOT READY mode to print
the configuration.
3.
Printer
Con–
figuration
PRESS
ST
AR
T T
O PRINT
PRESS STOP TO EXIT
You are prompted to press the
Start key before the
configuration prints.
4.
Start
NOT READY
Indicates that the
configuration has printed.
Date and store the printout in
a safe place. You may also
want to label the printout
(e.g. “Configuration for 2-up
Labels”).
5.
Start
READY
The printer is READY for
normal operation.
The second method for printing the current configuration, as well as several
other configurations, is to use the Print Custom Set Values menu option,
shown on the following page.
