2–13
Chapter 2. Setting Up the Printer
Remove the Cardboard Packing and Envelope
Cardboard
Packing
Cardboard
Packing
Figure 2–4. Removing the Cardboard Packing and Envelope
1. Raise the printer cover.
2. Remove the cardboard packing.
3. Open the tractor doors. Push the tractor locks down. Slide the tractors
outward as far as they will go. The forms thickness lever should be in the
fully open (raised) position.
4. Remove the envelope that contains the sample configuration printout.
Store this in the pouch that is attached to the left interior side of the
cabinet.
To Next Page
