2–17
Chapter 2. Setting Up the Printer
Release the Paper Chains
Tie Wrap
Plastic
Bags
Tie Wrap
Paper
Chains
Figure 2–8. Releasing the Paper Chains
1. Open the rear cabinet door.
2. Cut the tie wraps and release the paper chains from the bags at the top
rear of the printer frame. Remove the tie wraps and bags. See Figure 2–8.
3. Make sure each chain hangs freely, with no kinks or knots.
