2–16
6400 Line Matrix Printers Setup Guide, Cabinet and Pedestal Models
Remove the Foam Strips and Protective Film
Foam Strip
Protective Film
Paper Support
Figure 2–7. Removing the Foam Strips and Protective Film
1. Slide the two paper supports toward the center of the support shaft.
Position them so that they divide the space between the tractors into
three approximately equal segments. See Figure 2–7.
2. Remove the foam strips and the tape securing the foam strips.
3. Carefully peel off the tape and lift the protective film off the operator
panel message display.
