2–9
Chapter 2. Setting Up the Printer
Ribbon
Spool
Shuttle Cover
Assembly
Tractor
Tractor
Splined
Shaft
Ribbon
Mask
Ribbon
Guide (2)
Forms Thickness
Lever
Hammer Bank
(beneath
shuttle cover
assembly)
Ribbon Hub
Hub Latch
Base
Casting
Platen
Figure 2–2. Cabinet Model Component Locations (Cont.)
