IDEC SmartRelay Manual
101
Programming IDEC SmartRelay
3.8 Configuring additional functions for IDEC SmartRelay
Viewing the software status and errors of IDEC SmartRelay
To view the software status and errors, follow these steps:
1. In the main menu, move the cursor to
: Press or
2. Confirm : Press O
3. IDEC SmartRelay shows you the diagnostics menu. Move the cursor to
: Press or
4. Confirm
: Press O. IDEC SmartRelay shows you the following display:
5. ou can select
to view the real-time status of the connection or to view the
firmware version of IDEC SmartRelay.
After you select
, you can press or to view the status of each connection.
Viewing the hardware status and errors of IDEC SmartRelay
To view the hardware status and errors, follow these steps:
1. In the main menu, move the cursor to
: Press or
2. Confirm
: Press O
3. IDEC SmartRelay shows you the diagnostics menu. Move the cursor to
: Press or
