IDEC SmartRelay Manual
83
Programming IDEC SmartRelay
3.7 riting and starting the circuit program
Closing the programming mode
hen you finish programming, you can exit the programming mode by following these steps:
1. Return to the programming menu: Press E
SC
2. Return to the main menu: Press ESC
3. Move the cursor to
: Press or
4. Confirm : Press O
IDEC SmartRelay is back in RUN mode:
3.7.8 Deleting a block
Consider the case where you want to delete the block B2 from your circuit program and
connect B1 directly to 1.
To delete this block, follow these steps:
1. Switch IDEC SmartRelay to programming mode.
(As a reminder, refer to the topic The four golden rules for operating IDEC SmartRelay
(Page 57)).
2. Select
: Press or
