IDEC SmartRelay installation and wiring
2.2 Installing/removing IDEC SmartRelay
2.2.2 all-mounting
Follow the instructions below to wall-mount IDEC SmartRelay by means of two mounting
slides and two M4 screws (tightening torue 0.8Nm to 1.2Nm).
N
ote
hen you do not wall-mount IDEC SmartRelay, always keep the mounting hooks in the
factory default positions, that is, within the data area given in the illustration above
otherwise, the mounting hooks may deform if they are exposed to hot and humid
surroundings for a long term.
0RXQWLQJKRRNV
