IDEC SmartRelay Manual
287
Technical data
A.3 Technical data: FL1F-M08C2R2
Notice: For volume load such as fluorescent lamps with capacitors, you must consider the
technical data of fluorescent lamp ballasts. If the current exceeds the maximum allowed surge
current, appropriate contactor relays must switch the flourescent lamps.
When you connect inductive load such as magnet or valve, it is recommended that you use
diode for DC power supply and surge absorber for AC power supply to suppress the counter
electromotive force.
A.3 Technical data: FL1F-M08C2R2
Electrical Life 100,000 operations minimum
(rated resistive load,
1800 operations / hour)
100,000 operations minimum
(rated resistive load,
1800 operations / hour)
Switching rate
Mechanical 10 Hz 10 Hz
Ohmic load/lamp load 2 Hz 2 Hz
Inductive load 0.5 Hz 0.5 Hz
FL1F-M08C2R2
Power supply
Input voltage 100 VAC/VDC to 240 VAC/VDC
Permissible range 85VAC to 265 VAC
100VDC to 253 VDC
Permissible mains frequency 47Hz to 63 Hz
Power consumption
• 100 VAC
• 240 VAC
• 100VDC
• 240 VDC
• 10mA to 30mA
• 10mA to 20mA
• 5mA to 15mA
• 5mA to 10mA
Voltage failure buffering
• 100 VAC/VDC
• 240 VAC/VDC
• Typ. 10 ms
• Typ. 20ms
Power loss at
• 100 VAC
• 240 VAC
• 100 VDC
• 240 VDC
• 1.1W to 3.5 W
• 2.4W to 4.8 W
• 0.5W to 1.8 W
• 1.2W to 2.4 W
Digital inputs
Number 4
Electrical isolation No
Number of high speed inputs 0
Input frequency
• Normal input
• High speed input
• Max. 4 Hz
• - -
Max. continuous permissible voltage 265 VAC
253 VDC
FL1F-B12RCC FL1F-H12RCC
