IDEC SMARTRELAY User Manual

Technical data
A.6 Technical data: FL1F-H12RCA/B12RCA
IDEC SmartRelay Manual
292
A.6 Technical data: FL1F-H12RCA/B12RCA
FL1F-H12RCA
FL1F-B12RCA
Power supply
Input voltage 24 VAC/VDC
Permissible range 20.4VAC to 26.4 VAC
20.4VDC to 28.8 VDC
Reverse polarity protection - -
Permissible mains frequency 47Hz to 63 Hz
Power consumption
• 24 VAC
• 24 VDC
• 15mA to 150 mA
• 15mA to 130 mA
Voltage failure buffering Typ. 5 ms
Power loss
• 24 VAC
• 24 VDC
• 0.4W to 3.6 W
• 0.4 W to 3.2 W
Backup of the real-time clock at 25 °C Typ. 20 days
Accuracy of the real-time clock Typ. ± 2 s/day
Digital inputs
Number 8, optional positive voltage or negative voltage
Electrical isolation No
Number of high speed inputs 0
Input frequency
• Normal input
• High speed input
• Max. 4 Hz
• - -
Max. continuous permissible voltage 26.4 VAC
28.8 VDC
Input voltage
• Signal 0
• Signal 1
L
• < 5 VAC/VDC
• > 12 VAC/VDC
Input current at
• Signal 0
• Signal 1
• < 1.2 mA
• > 2.6 mA
Delay time at
• 0 to 1
• 1 to 0
• Typ. 1.5 ms
• Typ. 15 ms
Line length (unshielded) Max. 100 m
Analog inputs
Number - -
Range - -
max. Input voltage - -
Digital outputs
Number 4
Output type Relay outputs
Electrical isolation Yes
In groups of 1
