A.7 Technical data: FL1F-M08D2R2
IDEC SmartRelay Manual
294
A.7 Technical data: FL1F-M08D2R2
FL1F-M08D2R2
Power supply
Input voltage 24VAC/VDC
Permissible range 20.4VAC to 26.4 VAC
20.4VDC to 28.8 VDC
Reverse polarity protection - -
Permissible mains frequency 47Hz to 63 Hz
Power consumption
• 24 VAC
• 24 VDC
• 20mA to 100 mA
• 8mA to 50 mA
Voltage failure buffering Typ. 5 ms
Power loss
• 24 VAC
• 24 VDC
• 0.5W to 2.4 W
• 0.2W to 1.2 W
Digital inputs
Number 4, optional positive voltage or negative voltage
Electrical isolation No
Number of high speed inputs 0
Input frequency
• Normal input
• High speed input
• Max. 4 Hz
• - -
Max. continuous permissible voltage
• 26.4 VAC
• 28.8 VDC
Input voltage
• Signal 0
• Signal 1
L
• < 5 VAC/VDC
• > 12 VAC/VDC
Input current at
• Signal 0
• Signal 1
• < 1.1 mA
• > 2.63 mA
Delay time at
• 0 to 1
• 1 to 0
• Typ. 1.5ms
• Typ. 15ms
Line length (unshielded) Max. 100 m
Digital outputs
Number 4
Output type Relay outputs
Electrical isolation Yes
In groups of 1
Control of a digital input Yes
Continuous current I
th
Recommended range of application ≥ 100mA at
12VAC/VDC
Max. 5 A per relay
Surge current Max. 30 A
Incandescent lamp load (25000 switching cycles)
at
1000W
