IDEC SmartRelay Manual
299
Technical data
A.10 Technical data: FL1F-J2B2
A.10 Technical data: FL1F-J2B2
FL1F-J2B2
Power supply
Input voltage 12/24VDC
Permissible range 10.8VDC to 28.8 VDC
Power consumption 15mA to 30 mA
Voltage failure buffering Typ. 10 ms
Power loss at
• 12 VDC
• 24 VDC
• 0.2W to 0.4 W
• 0.4W to 0.8 W
Electrical isolation No
Reverse polarity protection Yes
Ground terminal For connecting ground and shielding of the analog
measuring line
Analog inputs
Number 2
Type Unipolar
Input range 0VDC to 10 VDC (input impedance 76 kΩ) or
0/4mA to 20 mA (input impedance <250 Ω)
Resolution 10 bit, normalized to 0 to 1000
Cycle time for analog value generation 50 ms
Electrical isolation No
Line length (shielded and twisted) Max. 10 m
Encoder supply voltage None
Error limit ± 1.5%
Interference frequency suppression 55 Hz
