IDEC SmartRelay Manual
289
Technical data
A.4 Technical data: FL1F-H12SCD
Notice: For fluorescent lamps with capacitors, you must consider the technical data of
fluorescent lamp ballasts. If the current exceeds the maximum allowed surge current,
appropriate contactor relays must switch the flourescent lamps.
A.4 Technical data: FL1F-H12SCD
Protection of output relay (if desired) Max. 16 A,
characteristic B16
Switching rate
Mechanical 10 Hz
Ohmic load/lamp load 2 Hz
Inductive load 0.5 Hz
FL1F-H12SCD
Power supply
Input voltage 24 VDC
Permissible range 20.4VDC to 28.8 VDC
Reverse polarity protection Yes
Permissible mains frequency - -
Power consumption from 24VDC 15mA to 50 mA (no load on digital output)
1.2 A (with max. load on digital output)
Voltage failure buffering - -
Power loss at 24 VDC 0.4W to 1.2 W
Backup of the real-time clock at 25 °C Typ. 20 days
Accuracy of the real-time clock Typ. ± 2 s/day
Digital inputs
Number 8
Electrical isolation No
Numbef of high speed inputs 4 (I3, I4, I5, I6)
Input frequency
• Normal input
• High speed input
• Max. 4 Hz
• Max. 5 kHz
Max. continuous permissible voltage 28.8 VDC
Input voltage
Signal 0
Signal 1
L+
< 5 VDC
> 12 VDC
Input current at
Signal 0
Signal 1
< 0.9 mA (I3 to I6)
< 0.07 mA (I1, I2, I7, I8)
> 2.1 mA (I3 to I6)
> 0.18 mA (I1, I2, I7, I8)
Delay time at
0 to 1
1 to 0
• Typ. 1.5 ms
<1.0 ms (I3 to I6)
• Typ. 1.5 ms
<1.0 ms (I3 to I6)
FL1F-M08C2R2
